Diaphragm Pump Graco Husky 716 Size 3/4 Inch, Jual Husky 716 Graco Diaphragm Pump

Diaphragm Pump Graco Husky 716 Size 3/4 Inch
Technical Specifications :
Maximum fluid working pressure : 100 psi (0.7 MPa, 7 bar)
Air pressure operating range : 30 to 100 psi (0.2 to 0.7 MPa, 2.1 to 7 bar )
Maximum air consumption : 28 scfm (0.672 cubic meters/min.)
Maximum free flow delivery : 16 gpm (61 l/min)
Maximum pump speed : 400 cpm
Gallons (Liters) per cycle : 0.04(0.15)
Maximum suction lift (water w/buna balls) : 15 ft (4.5 m) dry,
                                            25 ft (7.6 m) wet
Maximum size pumpable solids : 3/32 in. (2.5 mm)
Sound power level (measured per ISO standard 9614--2)
* At 70 psig (0.48 MPa, 4.8 bar) at 50 cycles per minute : 77 dBa
* At 100 psig (0.7 MPa, 7 bar) at maximum cycles per minute : 95 dBa
Sound pressure level (measured 1 meter from pump)
* At 70 psig (0.48 MPa, 4.8 bar) at 50 cycles per minute : 67 dBa
* At 100 psig (0.7 MPa, 7 bar) at maximum cycles per minute : 85 dBa
Air inlet size : 1/4 npt(f)
Air exhaust port size : 3/8 npt(f)
Fluid inlet size : 3/4 npt(f)
Fluid outlet size : 3/4 npt(f)
Wetted parts (in addition to ball, seat, and diaphragm materials, which vary by pump)
Aluminum pumps : aluminum, stainless steel, PTFE, zinc-plated steel
Non-wetted external parts : polypropylene, stainless steel, polyester (labels),
nickel-plated brass, epoxy-coated steel (feet)
Weight Aluminum pumps : 8.5 lb (3.9 kg)
