Diaphragm Pump Graco Husky 1590, Jual Diaphragm Pump Graco 1 1/2 Inch
Rp 123
Deskripsi Produk
Husky 1590 Air Operated Double Diaphragm Pump
The Husky 1590 air-operated diaphragm pump features a patented, high-reliability closed center air valve that is online serviceable and an epoxy-coated air section for tough environmental conditions.
Technical Specifications
Type : Pneumatic diaphragm pump selector
Seat Material : TPE
Ball Material : Acetal
Diaphragm Material : TPE
Compatible Material: Antifreeze, Detergents, Motor Oil, Hydraulic Fluid, Cutting Oil, Water - Wastewater Transfer
Maximum fluid working pressure : 120 psi (8.4 bar, 0.84 MPa)
Maximum free flow delivery : 100 gpm (378.5 lpm)
Maximum pump speed : 200 cpm
Displacement per cycle : 0.5 gallon (1.96 liter)
Maximum size pumpable solids : 0.19 in (4.8 mm)
Maximum operating temperature : 150°F (65.5°C)
Maximum air consumption : 125 scfm (3.5 m3/min.)
Air inlet size : 1/2 npt(f)
Fluid inlet & outlet size : 1-1/2 npt(f) or bspt(f)
Weight : 33.5 lb (15.2 kg)
The Husky 1590 air-operated diaphragm pump features a patented, high-reliability closed center air valve that is online serviceable and an epoxy-coated air section for tough environmental conditions.
Technical Specifications
Type : Pneumatic diaphragm pump selector
Seat Material : TPE
Ball Material : Acetal
Diaphragm Material : TPE
Compatible Material: Antifreeze, Detergents, Motor Oil, Hydraulic Fluid, Cutting Oil, Water - Wastewater Transfer
Maximum fluid working pressure : 120 psi (8.4 bar, 0.84 MPa)
Maximum free flow delivery : 100 gpm (378.5 lpm)
Maximum pump speed : 200 cpm
Displacement per cycle : 0.5 gallon (1.96 liter)
Maximum size pumpable solids : 0.19 in (4.8 mm)
Maximum operating temperature : 150°F (65.5°C)
Maximum air consumption : 125 scfm (3.5 m3/min.)
Air inlet size : 1/2 npt(f)
Fluid inlet & outlet size : 1-1/2 npt(f) or bspt(f)
Weight : 33.5 lb (15.2 kg)
